A ride on Kuala Lumpur’s railways

Wednesday, June 24th, 2009

A few pictures showing railways in and around Kuala Lumpur which I took in March 2002. Please note that the text is now somewhat out of date.

Kuala Lumpur seems to be trying to collect as many forms of rail transport as possible, with a conventional metro, an automatic metro, two different railway gauges and a monorail!

Putra

[Putra train]
One of the 70 linear induction motor powered vehicles on the Putra (Projek Usahasama Transit Ringan Automatik) metro.

[Kuala Lumpur skyline]
A view over Kuala Lumpur city centre from the front of a train. The trains are driverless, so passengers get a clear view out of the front window.

[View from train window]
The 29 km Putra metro is fully automatic.

KTMB

The KTM Komuter network is centred on Kuala Lumpur. Electrification began in 1995, and 160 km is now wired at 25 kV 50Hz AC. EMUs run from Seremban, south of KL on the main line to Singapore, to Rawang in the north, taking two hours. The second Komuter route provides Sentul to Port Klang services, which take about 1·5 hours.

Both routes pass through KL Sentral and Kuala Lumpur stations in the capital city, and run regularly from about 05.30 to midnight.

[Station]
The old station building in central Kuala Lumpur dates from 1886.

[Station]
To the north of and contiguous with the old station are more modern facilities, where all the train seemed to be stopping. The old station has a train shed and open access to the platforms, the new has substantial canopies and automatic ticket barriers controlling access. Platform heights vary between the parts. There is another new station, KL Sentral, to the south.

[KTMB locomotive]
Locomotive at KL

[KTMB shunters]
Shunters at KL

[KTMB locomotive]
Locomotive in KL station

[KTMB locomotive]
A locomotive at Rawang, the northern terminus of electrifed services in March 2002. Work is underway to double track and electrify the line northwards to Ipoh.

[Shunting locomotive]
This 0-6-0 diesel shunter was lurking at a cement works near Padang Jawa on the Port Klang line.

[EMUs]
KTMB metre-gauge EMUs stabled at Rawang, north of Kuala Lumpur.

[EMU interior]
Inside an EMU.

[EMU]
Another EMU, in the suburbs of Kuala Lumpur.

Star

[Star metro]
The Star metro in Kuala Lumpur is 27 km long, and serves 25 stations. Line 1 opened in 1996, Line 2 in 1998.

[Star metro train]
A Star driving car. Unlike Putra, Star is not automated.

Express Rail Link

[Express Rail Link]
View from the cab of a test train on the Express Rail Link. A KTMB train is on the metre-gauge line to the right.

[Express Rail Link Desiro train]
Our airport-bound test train passes another Siemens Desiro heading towards KL Sentral.

A visit to the Harzer Schmalspurbahnen

Tuesday, June 16th, 2009

Some (rather badly scanned) photographs I took while on holiday in Germany in July 2003, along with an article I wrote for Eagle, the journal of the Cambridge University Railway Club.

[Steam loco at water crane]
99 7238-1 takes on water at Drei Annen Hohne. 2003-07-18.

The famous Harz narrow gauge railway network is operated by Harzer Schmalspurbahnen GmbH. Owned by the various local authorities, it still provides scheduled steam services on the 131.24 km network, which became the first non-federally owned railway in the former East Germany on 1 February 1993. HSB declares its aim as to “preserve all three railways in the Harz region in their entirety as a tourist attraction, a monument to engineering, a facility for freight haulage and as a local transport facility”. HSB has 25 steam engines, six railcars, and 16 diesel locos.

We began our July 2003 visit to the Harz in Wernigerode. An attractive town, it looks rather like a German theme park might be built, with brightly-painted and half-timbered buildings. The Harz railways station is, as so often in Europe, located just outside the main station. Stepping off our DB train we could see smoke rising in the distance, but the DMU from Halberstadt had been 44 minutes late, so out priority was finding the Youth Hostel.

The hostel was a surprisingly respectable place, though a bus ride from the town centre, and not as well sign-posted as it could be! From the window of our room it was just possible to see passing steam trains through the trees. Dumping our bags we headed into town for dinner in the restaurant under the Rathaus – being a major tourist centre, there are plenty of dining options in the town. We wandered over to peer over the fence at the railway sheds, and bumped into a local who explained all about what Bismarck did in the dramatically-sited castle, but sadly our German wasn’t up to it.

The next morning we headed into town to photograph the 08:44 departure from Westerntor station cross a large level crossing outside the western gate to the town centre. We then walked to the main station to acquire tickets. The staff were well used to tourists, and with schoolboy-German and pointing at the map we were soon sold a suitable ticket. This was a €24 BrockenCard, valid for one return trip from any HSB station to Schierke and Brocken, and one other, non-Brocken, return trip within three days. A three day rover ticket costs €35, 5 days €40 and 7 days 50.00. Dogs under 20cm high go free, but bigger ones are half-fare.

We caught the 09:25 from Wernigerode to Brocken, hauled by 99 7238-1, and very busy with German holiday makers. The trains are formed of balcony carriages of a design common to the former-DDR’s narrow gauge lines. Riding on the balcony was popular, but Germans are averse to open doors. One chap held his nose to point out that the carriage might start to smell of steam if the door was left open, and leaving us to wonder why he was sat in the front carriage. It was clear that some of the Germans found their own insistance on keeping the doors close rather amusing, and they were slightly theatrical in closing doors after returning from trips to stand on the balcony!

[Loco in the mist]
The loco runs round its train at Brocken station, 1125 metres above sea level. 2003-07-18.

The train arrived at the 1125m high Brocken station at 11:07, disgorging its passengers into the misty and slightly cooler surroundings. There is the typically German collection of sausage sellers, a restaurant and a hotel at the top of the 1142m high hill. The former military listening post is now a visitor centre with information on the national park, local wildlife and history. We bought postcards, but didn’t pay the €4 go in. There is a ban on using the train toilets between Schierke and Brocken, and we soon began to wonder if this was anything to do with charging people €0.50 for the ones on the hilltop! We wandered over to the railway to photograph 99 7242-3 hauling the 11:52 arrival, before boarding for the 12:08 back down.

[Steam loco in trees]
2-10-2T locos 99 231 to 99 247 were built at Karl Marx Locomotive Factory in Babelsberg in the 1950s for use on the narrow-gauge Eisfeld – Schönbrunn, Gera-Pforten – Wuitz – Mumsdorf, Harzquer and Brocken lines. Carrying its former DR number, 99 7234 is heading up to Brocken, while the downhill train waits in the passing siding. Once the uphill train has passed, the downhill train reverses out of the siding back onto the main line, then heads forwards to Schierke. 2003-07-18.

Halfway to Schierke the downhill train runs into a siding, where it waits for the uphill train to pass. The downhill train then reverses out of the siding, before heading forwards again. Throughout the journey staff wandered up and down the train with baskets, selling small bottles containing some form of alcoholic beverage.

We got off at Schierke, to watch the trains pass and grab some currywurst and bottled black beer, and be impressed by the range of tacky witch-themed souvenirs in the station shop (the German witches who apparently meet on the Brocken seem to wear a lot less clothing than British ones!). We then took the 13:40, seven coaches and a van hauled by 99 7234-0, down to the junction at Drei Annen Hohne, where the station features a beer garden, and there is a tourist information centre. After 15:00 we had the now unusual sight of three scheduled steam trains waiting to depart in three different directions.

The loco from the Eisfelder Talmühle – Wernigerode train, which includes an open wagon fitted with seating for which a supplement is payable, is swapped with the loco from the Brocken – Nordhausen train. The Wernigerode – Brocken train keeps its loco.

At 15:33 we set off for Nordhausen behind 99 7236-5. At Elend there was a slight pause as the station cafe supplied mugs of drinks for the loco crew.

The countryside is heavily wooded, and many trees later we arrived at Eisfeld Talmühle, junction of the two routes. A diesel railcar connection arrived from Nordhausen and went off towards Steige. The station building seemed to be under reconstruction, and there was a collection of freight rolling stock in DR livery stood in a siding. We passed through Ilfeld, the northern limit of a more frequent service which provide about one railcar an hour to Nordhausen, but at irregular intervals.

Nordhausen – closed for rebuilding

[Railcar]
There is short link between the HSB lines and the tramway in Nordhausen, allowing railcars to serve Nordhausen Nord, the bus and tram stop.

187 016-1 is one of four diesel-hydraulic railcars built to reduce costs on Alexisbad – Nordhausen Nord services and to provide school and commuter services between Ilfeld and Nordhausen. Partly paid for by the states of Thüringen and Sachsen-Anhalt, the 50km/h railcars were built at DB’s Halberstadt works and delivered from March to August in 1999. The design was developed using experience gained with prototype vehicle 187 015 which had been built in Wittenberge in 1996. (Photo 2003-07-18).

The HSB terminus in Nordhausen, just to one side of the DB station, gives the distinct impression of having seen better days. The one modern feature among the decay is the provision of a short link between the HSB and the town’s tram network. Branching off the HSB just before the station, this allows the HSB railcars to access the bus and tram stops in front of both railways’ stations.

The tram network comprises two lines electrified at 600 V DC. The 3.22 km Line 1 runs from the hospital in the north to the station in the south, the 4.55 km Line 2 runs from Parkallee in the northwest to Nordhausen East, crossing Line 1 in the town centre. During our stay much of the city centre was being dug up for rebuilding, and instead of serving the station via a large loop around the block the trams were terminating in a construction site a few minutes walk away.

The tramway was obviously having serious money spent on it, with some of the stops being modernised to light rail standards. In 2002 the town ordered 3 dual-mode Siemens Combino trams with 180 kW diesel engines, and from May 1 2004 these will operate an hourly service on a new Route 10 from the hospital, through the town centre and then under diesel power over the HSB lines to Ilfeld. We noticed that the southern end of the HSB also had very modern platforms, perhaps in readiness for the integration with the tramway.

[Tram]
Three-section Siemens Combino tram number 105 tram negotiates the road and tramway rebuilding works in central Nordhausen. The tramway is operated by Stadtwerke Nordhausen. (Photo 2003-07-18).

The city has a fleet of 7 Siemens Combino trams, a mix of uni- and bi-directional models. No. 107 was carrying vinyls referring to the tramway in the Austrian town of Gmunden where it had recently been demonstrated. Only having doors on one side of most of the trams was awkward in the city centre, where rebuilding of the southbound track meant all trams were using the other line, making the doors inaccessible from the platform.

Tickets are bought from machines on board the tram, which seemed to be quite new as some locals were struggling with it. While we debated whether it was worth getting a four-journey ticket, a local thought we were confused and came to offer help. Then the tram stopped, luckily on a reserved track section, and the driver came back to join in!

The youth hostel is one stop from the northwestern terminus of Line 2, but within walking distance of the town centre; the tramway really is tiny. Outside the hostel were two sidings in a locked compound containing older trams, now displaced by the Combinos.

Like so many towns Nordhausen was devastated by air raids in WWII (V2 rockets were produced in a nearby labour camp), was perhaps unsympathetically rebuilt, and is only now being restored; it is quite odd to see a section of medieval city wall being built! The whole town gave the impression of being shut for rebuilding. We ate at a cheap bar round the back of the Rathaus, which was the only sign of life we could see. We weren’t unduly disappointed to be leaving Nordhausen the next morning, but I think it will be a reasonable place once they have finished building it, though with few attractions other than its transport network.

Down the pit

At 10:06 the following day we set off for Netzkater behind 99 7236-5. We had planned to change trains one stop further on at Eisfelder Talmühle, but on the way in we had spotted a mining museum with a collection of narrow gauge rolling stock, and a beer garden.

A tour of the mine was departing as we arrived at the museum, and after relieving us of €5 the ticket office simply gave us hard hats pointed towards the drift entrance. We dashed down after the tour group, for a 45 minute walk around the disused coal mine. The tour was in German, but if you have ever done a tour of a mine you can work out much of what was being said and fill in the gaps! Part of the tour is completely unlit, visitors having to feel their way forwards through the tunnels. There was a demonstration of a cable hauled incline inside the mine, then we returned tot he surface, where for €0.50 rides on a 60cm gauge man-rider train were available. A beer later we caught the 12:10 diesel railcar for Hasselfelde on the Selkatal line.

Limitations of GCSE German

All but one of the other passengers disembarked at Stiege, but we continued to Hasselfeld. The ‘genuine’ passenger left, and the driver retired to the station cafe. We wandered around the station yard, where a steam loco boiler is on display. A shed contains another loco, which we think is privately owned and non-operational. We then returned to Steige, where the passengers who had got off earlier got on again! There were now 13 passengers,and the other 11 seemed fairly genuine, rather than simply there for the ride. In contrast, all seven or so coaches of the trains on the Brocken line had been pretty full.

An uphill train approaches the Brocken summit. 2003-07-18.

Numbers had thinned to four by Siberhütte. As we approached the station a stout gentleman in a bright pink shirt could be seen rushing towards the station, followed by a snaking line of 10 hikers. Unfortunately the train left the station before he made it to the platform. This left us with a problem, as I was off school during the “bang on the cab door and tell the train driver he had left the passengers behind” module of GCSE German. We pointed out to the other two passengers what had happened, and after some hesitation they went to establish communications with the driver. We stopped some distance beyond the station, and I hung out of the window to wave and shout at the hikers, who came trotting along the track behind us to catch up.

We got off at Alexisbad, the junction for the Harzgerode brach, and took the change to sample the local apple wine. A steam train arrived from Gernrode, and we caught it up the steeply graded branch. Many of the passengers seemed to be enthusiasts, and there were a few British people on board. A the terminus there was just time to glance into the castle courtyard, then it was time to head back down to Alexisbad, and change for a steam service to Gernrode.

The station area at Gernrode cannot be considered one of Germany’s greatest scenic delights. After ascertaining that the semi-derelict structure opposite the HSB terminus really was the DB station, and inferring from the presence of another, local-looking, passenger that there might really still be a train service, we had the best part of an hour’s wait for our two-car DMU. This took us to the very attractive town of Quedlingburg, which has an impressive gothic-style station, and a centrally-located – and this time well sign posted – half-timbered youth hostel where we were given a room in the attic.

Visiting

The Harz railways are well worth a visit. Wernigerode is geared up for tourists, and the Brocken line is very popular. The use of steam over the whole system can feel slightly “preserved”, but I felt the Selketal line had a slightly more genuine feel to it, with real passengers, and the railcars certainly provide a real service.

The one thing to beware of when planning a trip is that south of Drei Anne Hohne the trains are not very frequent, with four services per day over some stretches of line. The pattern of through trains is quite complex, and a trip over the whole network does require some planning.

HSB’s official website at gives full timetables, details and histories of the lines, and enthusiast oriented information on the rolling stock in both German and English.

Export Class 158 in Thailand

Tuesday, June 16th, 2009

[State Railway of Thailand class 158 DMU]

State Railway of Thailand operates some diesel multiple units which are export versions of BREL’s British Rail Class 158s.

Obvious differences from their British cousins include metre gauge bogies, the primitive connections between cars, and a squat toilet. Underneath the advertising vinyls, the livery is remarkably similar to the colour scheme which the British DMUs once carried!

Although I didn’t get a ride on one, I had a quick look inside a set which was stood at Bangkok Hualamphong station waiting to form the 16:20 Bangkok – Chachoengsao service on 30 October 2005.


[SRT class 158 DMU]

[SRT class 158 DMU]

[SRT class 158 DMU]

[SRT class 158 DMU]

[SRT class 158 DMU]

Inside

Okay, I should have used the flash.


[SRT class 158 DMU]


[Warning sign in SRT class 158 DMU]

[Gangways on SRT class 158 DMU]

Warning
Please be careful walking across
the bogie joint while the train
is on operation

Other trains

I had a ride on one of these:


[SRT DMU]

From Bang Sue to Hualampong station, the main terminus in Bangkok.


[Bangkok station concourse]

As the Vogel flies

Sunday, June 14th, 2009

Or, to bee or not to bee

The “Bird-flight line” between Germany and Denmark uses one of the last passenger train ferry services in Europe, providing a direct route from Hamburg to Copenhagen “as the bird flies”.

Hamburg to Copenhagen train at Hamburg Hauptbahnhof

There’s no way the ticket machine is going to be able to cope with this, I thought, giving it a go anyway. What hope is there of getting a foreign machine to sell a future-dated ticket for a cross-border trip, on a service which is partly reservation-only, includes a ferry, and calls at a station which doesn’t exist – in the middle of the sea? With a break of journey in the next country. Oh, and a foreign credit card.

But Deutsche Bahn’s latest technology beats the our old Quickfares, and a couple of minutes later I was leaving Lübeck station clutching enough paper to keep the forest products industry in business for the next week; the ticket, two reservations, a receipt and a list of timings. All issued in English, and after offering me timetable information and a choice of fare options.

Back in September 2007 I’d got an invitation to the opening of a new bit of metro line in Denmark, and having some holiday to use up I thought I’d take a route which was a bit more scenic than a tin box direct from Gatwick to København.

The Danish and German governments had recently agreed to build a bridge across the Baltic to replace the current Fehmarn Belt train ferry, so this seemed a good opportunity to sample the sea crossing – not that there is too much of a rush, as the bridge won’t open until 2018, if it happens at all.

Step one was getting to Germany. Eurostar hasn’t really caught on to one-way trips, and while DB’s whizzo ticket machines might be wonderful their sleeper train website was sulking, so a search online found me a “how do they maintain the planes at that price?” flight to Bremen with everyone’s favourite Irish airline, leaving darkest Essex the next day.

Metronom double deck train at Bremen Hauptbahnhof

A mere 15 min after landing in Bremen I was on the tram stop outside the air terminal. Just 20 min after landing I was back in the airport seeking somewhere to buy a ticket, and only 25 min after landing I was on a tram to the Hauptbahnhof. From here I caught a couple of double-deck trains via Hamburg Hauptbahnhof to the strangely deserted city of Lübeck, and its handily central youth hostel – staying in Lübeck meant the next morning’s departure time would be at a more civilised hour than if I joined the København train at its start point in Hamburg.

Class 218 diesel loco at Luebeck Hauptbahnhof

The railway from Hamburg to Lübeck is currently being electrified – by the time you read this, it probably will have been – which will bring the demise of the “rabbit-ear” exhaust Class 218 diesel locos which currently power double-deck push-pull trains on the route. On a previous visit in March 2007 the station had been a building site, but by September the overall roof had been completed, and the heavily-rebuilt station had a modern and efficient air about it.

I’d seen the Hanseatic city’s sights before, so it was time for a meal, ein bier, and bed. Thanks to the wonderful ticket machine I was already booked on the next day’s 08:07 train to Denmark.

Leaving Lübeck

In September the Hamburg to København service was operated with Danish State Railways’ IC3 DMUs, three-cars units with “rubber ring” ends (and not to be confused with the German ICE3 high speed trains). Built by ABB Scania before it became Adtranz and then Bombardier, the 180 km/h units aren’t the prettiest things on rails, but the spacious interior makes the most of a loading gauge somewhat larger than ours. With the December 2007 timetable change DB’s ICE-TD tilting inter-city DMUs have been transferred to the route, the national railway finally having found a home for what have provided troublesome trainsets (one got dropped and bent in a depot accident, like the unfortunate Hull Trains Pioneer DEMU).

Passengers at Luebeck Hauptbahnhof

Reservations are compulsory on the German leg of the trip to Denmark, but my seat was firmly occupied so I bagged a spare seat across the aisle; after a few seconds of the “music” from a fellow passenger’s headphones I decamped to the next carriage.

We left Lübeck slightly late, and headed north for an uneventful 89 km trip across a flat and nondescript landscape. The final stretch of this line was built specifically for international trains, as part of a grand plan to significantly shorten the time needed to travel between eastern Denmark and Germany.

Making a Bee Line

By the early twentieth century it had become clear that better links were needed between København and Germany. One of the travel options was to take a train to the Danish port of Gedser, then make a long sea crossing to Warnemünde on the north German coast. The alternative was to take a train across Sjælland (Zealand) from København to the Storebælt (Great Belt). Here you caught a ferry across the strait to the next island, Fyn, which was then crossed by train until you hit the Lillebælt (Little Belt). A second ferry then took you on to the Jylland (Jutland) peninsular, from where you could get a train south to Germany. A bridge across the Lillebælt was opened in 1935, permitting a through rail journey once you were west of the Storebælt, but that still had to be crossed by ferry and it was all a bit of a long way round.

Puttgarden to Rødby train ferry

By the end of the 1930s plans had been firmed up for new link, which would use a relatively short sea crossing between the Danish island of Lolland and its German opposite number Fehmarn. New bridges would link each island to the respective national road and rail networks. Joining together the islands dotting the shortest route across the Baltic, this route is in effect a straight line between Hamburg and København, and could even be stretched, with some cartographic licence, on to Stockholm and Köln. The proposed route became known as the Vogelfluglinie in German or Fugleflucts Linien in Danish, meaning Bird Flight Line, in the sense of “as the crow flies”. This sometimes gets translated into English as the “Bee Line”.

The first step was the opening of the 3.2 km Storstrøm bridge in 1937, providing a road and rail link between Sjælland and the island of Falster, but further progress was interrupted by the outbreak of war. The plans were dusted off again after the German occupation of Denmark, and in 1941 the Danish parliament agreed to construct the rail and motorway links for their end of the scheme. Work began immediately, and about 13 km of civil works were completed at a cost of 7.7m krone before being put aside for another day in the face of more pressing matters.

Peace created a problem for the long eastern sea route from Gedser to Germany. The ports of Warnemünde and Sassnitz were now in East Germany, and transit to the areas under the control of the western powers was no longer possible. Traffic from Scandinavia to western Europe had to go round via Jylland, and the Storebælt ferries couldn’t cope with demand.

To keep things moving a temporary ferry service was introduced on 14 July 1951, running from Gedser to a new facility built at Grossenbrode in what was now West Germany.

By 1958 West Germany had recovered to the extent that it was in a position to take another look at the plans for the Bird Flight Line, and a new Danish act of parliament approved the re-start of work on a revised scheme.

Puttgarden train ferry terminal, Germany

At the German end the railway from Lübeck to Grossenbrode was resignalled and upgraded for higher speeds, while 18 km of new line was built to a new ferry port at Puttgarden on the island of Fehmarn. The railway crosses from the mainland on a 960 m bridge, which includes a 250 m arched main span taking the single track line and a parallel road 23 m above sea level. Work on the bridge began in January 1960, and it opened in April 30 1963, with the island’s ferry service closing the same day.

A second ferry port was built at Rødbyhavn, near the town of Rødby on the Danish island of Lolland. A meandering private railway already ran there, but the new terminal was linked to the Danish State Railways (DSB) network with the construction of a line running for 37 km straight across the island. A swing bridge carried the new line above the Goldberg sound and on to the neighbouring island of Falster. At Nykøbing it joined up with the railway to Gedser, the port for the temporary service to West Germany which the Bee Line would replace. The new line was built without level crossings, instead needing numerous bridges because of the flat landscape.

The German and Danish ferry ports were just 18 km apart by sea, a substantial saving on the previous 69 km route from Gedser to Grossenbrode. This cut a København – Hamburg trip to just 6 h 15min, compared with 9h 20min via the Great Belt or 8 h via Gedser and Grossenbrode. It now takes about 4½h.

The Bird Flight Line service was inaugurated on May 13 1963, using DB ship Deutschland and DSB ship Kong Frederik IX, which were transferred from the temporary Grossenbrode to Gedser route. Also transferred was Theodor Heuss, which had entered service on November 1957.

Rødby - Puttgarden ferry "Prins Richard"

The route proved a success, and traffic continues to grow. Modern ferries operated by Scandlines now leave each port every half hour around the clock, and are timetabled to take 45 min for the crossing. Not every sailing carries a train – there are six Hamburg – København train pairs a day.

In June 2007 the Danish and German governments finally agreed to build a 19 km bridge to replace the ferries. Work is planned to start in 2011 and the bridge is scheduled to open in 2018, but this is dependent on Denmark stumping up the money; the Germans have said that if the Danes want a bridge they will happily go along with it, but they won’t pay for it.

All at sea

Puttgarden to Rødby train ferry

The train stopped briefly in the station at Puttgarden, before running forward into the bowels of the ship quite simply and unexcitingly, at least from the passengers’ point of view. The train doors opened, and passengers started to wander off; it was obvious that I wasn’t the only one who was unsure as to whether he could his bag on the train. The train parks on the car deck, with a lorry behind it, and passengers mingle with road users as they head upstairs to the lounges.

Forget romantic notions of chaps in horned helmets [yes, yes, I know] taking to the high seas in this part of the world. Built in Denmark in 1997, Prinsesse Benedikte is a sort of floating motorway service station, with bars, a closed restaurant and a dedicated lounge for lorry drivers. The duty free shops were closed, perhaps permanently.

Having walked round the ship in both directions I headed to the buffet, joining the locals in a game of seeing how much hot coffee it is possible to get into a serve-yourself paper cup without burning yourself.

Puttgarden to Rødby train ferry

Up on the inappropriately-named sun deck passengers were watching the busy maritime traffic of this corner of the Baltic. There are ships visible in every direction, but also lurking out here amongst the waves is an honorary railway station, Puttgard MS. A figment of the ticketing system, the notional Mittlesea station allows holders of tickets for one country to buy a ticket for the other country, starting right at the international border.

Arrival in Denmark is as unexciting as the departure from Germany, the ferry slowing past the breakwaters as it enters Rødbyhavn. To save time at the ports the ships are double-ended, with a bridge and doors at both ends so there is no need to turn vessels round.

Denmark

There was an obvious movement of passengers towards the car deck as we approached Danish terra firma. The train is the first vehicle off the ship when the doors open, passing through a vast area of derelict sidings left over from the days when borders were real borders. The station was built for 15-coach loco hauled trains, rather than today’s three car DMUs, and yard tracks were laid out so that a complete ferry load of wagons could be in position and waiting to be shunted on board as soon as the ferries docked.

All rail freight traffic now goes round via the Storebælt and Jylland, with the Øresund bridge as newest link in a chain which enables freight to be hauled from Sweden to through to Germany with just one multi-voltage loco.

The scenery continues to be unexciting, with minor interest provided by the bridges between the islands. The Guldborg Sound between Lolland and Falster is crossed on a precast concrete bridge, actually two parallel structures, one for the single track railway and one (which is itself two interlinked structures) carrying the road. Trains are now back on the original line to Gedser, and cross to Sjælland on the 3.2 km road and rail Storstrøm bridge built in 1937.

Roskilde cathedral interior, Denmark

At Ringsted we join the main line from Jylland to København, and not long after we pull into the ancient ecclesiastical capital Roskilde, where there is an impressive cathedral. The past few centuries worth of Danish monarchs are buried here in neat numerical order, including the railway enthusiast Frederik IX whose final journey to the cathedral in 1972 was steam-hauled; his wife left instructions to use the same locos for her own funeral in 2000.

Viking ship museum in Roskilde, Denmark

The sea crossing on the Bird Flight Line is efficiently dull, but the glory days of Danish maritime matters can be recreated at a museum by down the shore in Roskilde. Five Viking ships when been extracted from the seabed and put on display, and replicas take people out into the fjord to experience a bit of Viking life (note to museum curators: I’m sure the Vikings were all into trade and poetry, but I want longships and pillage for my krone).

The ride onwards to København on an EMU packed with school children was uneventful, and no-one even asked to see my heap of tickets.

København H station

References

  • Train Ferries of Western Europe, P Ransome-Wallis, Ian Allan 1968
  • The Rodby-Fehmarn Route (The Bee-Line), K Gulstad, Chief Permanent Way Engineer, DSB. Railway Gazette, 18 May 1962, pp565-571

Øresund: around the Sound

Sunday, June 14th, 2009

Little Mermaid statue

Having arrived in Denmark by train ferry, the next morning I caught a train north to Helsingør, or Elsinore as the Danes insist in calling it in English, and then continued by ferry across the Øresund, the strait separating Denmark from Sweden.

Preliminary research had told me that an “Around the Sound” ticket was available, valid for rail, bus and ferry travel on either side of the Øresund. It gives unlimited regional travel in the relevant bits of Denmark and Sweden, plus a single train journey across the Øresundsbron international bridge, and one trip in the opposite direction on the Helsingør – Helsingborg ferry.

S-Tog in Copenhagen

Unfortunately, it turned out that this useful sounding ticket is only sold in Sweden. The staff at København’s main station were obviously used to dealing with misinformed tourists, and so issued me with the appropriate single tickets for today and tomorrow instead.

The frequent international train services around the Sound are run by a fleet of Adtranz EMUs, “rubber ring” ended sets equipped to run on 25 kV AC at the Danish side and 15 kV in Sweden. The interiors are spacious, but the trains have had some technical problems since they were introduced.

Helsingør

Trains at Helsingor, Denmark

On the coast 46 km and 44 min north of København, Helsingør is the Danish end of the U-shaped cross-Øresund service, and trains terminate in a large harbour-side station which is fully integrated with the adjacent ferry terminal. While I was looking round a modern DMU crept in through a gap in the wall on the landward side of the station. This is the Hornbækbanen, a 25 km local railway independent of state railway DSB, but I wasn’t sure where the train might be going or how to buy a ticket, so gave it a miss.

Train at Helsingor, Denmark

Leaving the station the local line runs alongside the road between the town and the harbour, providing a good photo opportunity across the harbour to Kronborg Castle. This UNESCO world heritage site is the reason everyone visits Helsingør, so it was duly ticked off. Hamlet didn’t actually live there, what with him being a fictional character, but it is well worth a look. In addition to the usual palatial things there is a maritime museum with walk-though replicas of parts of ships, and there is a giant in the cellar. You’ll never guess which play they were setting up a stage to perform…

Over to Sweden

Helsingor

After lunch it was time to go back through the rain to the station, into the ferry terminal and onto the next sailing for Sweden. A continuous shuttle of boats makes the 20 min crossing between Denmark and Sweden, visible through the drizzle across the Sound. It isn’t very far across, just 4 km or so, and the guns of Kronborg Castle allowed Denmark to control access between the North Sea and the Baltic. Denmark charged a toll to allow ships to pass, but by 1857 the rest of the world had got so fed up that they clubbed together and gave the Danes a huge wodge of cash to scrap it.

Helsingor to Helsingborg ferry

Passengers are disgorged from the ferries into a modern terminal at Helsingborg, the Swedes carrying as much beer as then can carry over from Denmark, where prices are marginally less obscenely high.

The trains are hidden beneath the ferry terminal, on an underground line paralleling the shore. I boarded another Øresund EMU, which would have left Helsingør 2 ¼ h before on its U-shaped journey. Many of the EMUs had the leading window of the middle carriage smashed and temporarily covered with a plastic sheet, apparently down to the actions of stone-wielding yobs in an area of Malmö (or at least that’s what a Dane told me – a Swede might blame the Danes).

I took the train as far as the cathedral and university city of Lund, which shares a name with a small village in East Yorkshire (common Viking heritage?).

Lund station, Sweden

Sleeping car

Youth hostel in railway sleeping cars at Lund, Sweden

København’s Youth Hostel is a towering multi-storey monstrosity, but Lund has a somewhat cosier hostel formed from a rake of old Swedish Railways sleeping cars, parked permanently in a siding behind the station.

One car houses the kitchen and dining room, one car the showers and others form the dorms. Inevitably it is a bit cramped, but it works.

On to Malmö

The next morning I continued on to Malmö in a rather startlingly purple local EMU, operated under a regional concession by our own Arriva.

Lund station, Sweden

Malmö’s Technical & Shipping Museum has a couple of steam engines, some planes, a submarine, and a heritage tramway which runs round the outside of a fortress and a picturesque fish market.

Vintage tram at Malmo transport museum

The city’s last regular trams ran in 1973, but the short museum line opened in the summer of 1987 to recreate the experience. Unfortunately it wasn’t running during my visit, which is perhaps not surprising as I had the museum almost to myself.

On the way back to the station I called in at the exhibition centre of the Citytunnel project. A new tunnel is being bored beneath the city centre, converting the existing terminus station into a through station.

Citytunnel construction site, Malmo

Trains to Denmark currently leave Malmö in the wrong direction, encircling the city in a wide loop to reach the Øresund bridge. The new tunnel will enable direct running, knocking a few minutes off the journey and eliminating the need for trains running further into Sweden to reverse in the station.

The construction site itself was visible to the public, with the work observed by the usual collection of old men who gather wherever there is a hole in the ground to be peered into.

Back on another Øresund train we passed round Malmö, before coming to the huge cable-stayed bridge linking Sweden to Denmark. Approach bridges more than 3 km long lead on and off the main span of 490 m, held 55 m above the sea by four 204 m pylons. Double decks carry the motorway above the railway as far as the artificial island of Peberholm, where road and rail switch to run through the four parallel tubes of the world’s longest immersed tunnel.

Opened by Queen Margrethe II of Denmark and King Carl XVI Gustaf of Sweden in July 2000, the bridge provides the final connection in a fixed link from Sweden to Germany, completing the route which began with the bridges taking trains between the Danish islands. Not long before I arrived it had been announced that international traffic over the Øresund bridge had exceed Danish domestic traffic over the Storebælt from Jylland for the first time, a significant and symbolic step in the re-orienting of the cross-border region’s business, transport and residential patterns triggered by the bridge.

EMU trains at Malmo C station
