Archive for the ‘Travel’ Category

Trains in Ontario

Friday, June 17th, 2011

In January 2001 I went to London, Ontario (where the Class 66 locomotives are built), and also had chance to take a train ride to Windsor and visit a freight yard in Toronto. These pictures some pretty grotty old scans, first uploaded back when downloading an image over dial-up could involve a long wait.

I went back to Canada in June 2004, this time touring the country by train.


Looking across from Windsor in Canada to Detroit in rebel-controlled North America.

[Preserved steam locomotive]
CN class K-3-b steam locomotive number 5588, formerly Grand Trunk Railway class P6 number 213. This pacific was built in 1911, and is now ‘stuffed and mounted’ in Riverside Drive, Windsor. It carries the name Spirit of Windsor. If you ever visit Windsor, it may be useful to know that the station is a long way from the city centre – I didn’t! It was about -7°C when I took this – maybe nothing special to the locals, but jolly cold for me.

[7260 in Windsor]
GY-418e number 7260 alongside the river in Windsor, with Detroit in the background. Originally build by General Motors in 1956 this locomotive was remanufactured at Pointe St-Charles main shops in Montreal in 1990. It is approved for operation in the USA, and is equipped for remote control operation.

Behind the locomotive is GP9 slug 253. This was converted from a cut-down General Motors GP9 in 1990. It has no engine, instead taking power for its traction motors from the locomotive.

[6424 at Windsor]
I caught the 09:55 departure from London to Windsor on 9 January. This set off from London about half an hour late, and was about an hour late into Windsor. A freight train in front of us was apparently having problems.

There is quite a difference in height between the loco and the three carriages.

[6424 at Windsor]
Another view of the locomotive about to run round. 6424 is a 3000 hp B-B built by General Motors in 1987, and is one of ten examples of the GPA-30b class. There were three orders for these GPA-30 passenger locos between 1986 and 1989, totalling 59 locos

[6426 at London]
Compared to the UK, Canadian trains are big. 6426 departs London for Toronto at 15:48 on 8 January 2001

[Amtrack train]
An Amtrak train bound for Chicago leaves London, 10am Tuesday 9 January 2001. The picture doesn’t really capture the size of the thing. The station doesn’t have raised platforms like the UK, just a tarmaced area next to the line, so the train really towers above passengers. There is a second platform, but that was under deep snow. The loco, number 519, is a GE B32-8WH of 1991.

[Disused station in London]
A disused passenger station on the CP line in London. Freight still comes through here. 8 January 2001

[Switcher 12]
This GP9 is one of three switchers (shunters) belonging to a private contractor that are used at the Canadian Pacific Railway’s Vaughan Intermodal Terminal near Toronto. Vaughan is the largest container freight yard in Canada, and sees trains up to 10 000 feet long! Seen here on 10 January 2001

[Switcher 1254]
GMD type SW1200RS B-B switcher of 1956. Formerly a CN loco, it now belongs to a contractor, and is also used at Vaughan. 10 January 2001.

[Switcher 7703]
GMD type SW9 of 1952, formerly belonging to Century Locomotive Parts, and previously a CN loco, but now belonging to a contractor and working at Vaughan yard. 10 January 2001.

[Loco 6046]
EMD SD40 or SD40-2(?) 6046 of 1952 at MacMillan Locomotive Reliability Centre, near Toronto.

[Loco 7276]
EM GY-418f 7276 at MacMillan Locomotive Reliability Centre, near Toronto. Originally build by General Motors this B-B locomotive was remanufactured by AMF Technotransport in 1993. 258

GP9 slug 258 was converted from a cut-down General Motors GP9 no 4411 (ex-1735) in 1990. It has no engine, and takes the power for its traction motors from the locomotive. It is equipped for remote control operation, and approved for use in the USA.

I found the details of the vehicles in the book Canadian Trackside Guide 1996, published by Bytown Railway Society Inc of Ottawa.

The Canadian

Friday, June 17th, 2011

Crossing Canada on VIA Rail’s The Canadian Toronto – Vancouver train service in June 2004, and continuing on to Vancouver Island.

[Lugagge at Jasper station]
Lugagge for The Canadian service being loaded (or unloaded) at Jasper station, 21 June 2004.

[Courtenay station]
The VIA Rail train from Victoria waits at Courtenay before heading back south. The railway on Vancouver Island is very scenic, but only had one daily passenger train each way. 23 June 2004.

[Victoria station]
Victoria station, at the south end of the Vancouver Island line. 23 June 2004.

Czech railways in 2003

Thursday, February 24th, 2011

In October 2003 I spent a week in the Czech Republic, touring the Czech rail network, and sampling the odd local beer or four.


[Photo of CD railbus 810 055-4]

Railbus 810 055-4 was part of the stock of the 12.36 from Marianske Lazne to Karlovy Vary dolni, where it is seen shortly after arriving at around 14.14 on 2003-10-05.


[Photo of EMU 451 068-1]

Electric multiple-unit 451 068-1 stands at Praha hlavni with service Os 9143, the 11.23 to Benesov u Prahy, on 2003-10-06. Despite the impressive front end the train was a bit grotty inside.


[Steam loco on level crossing]

The 120th anniversary of the Krupa – Kolesovice line was celebrated on 4th and 5th October 2003. Steam loco 434.2186 hauled a Praha Masarykovo – Kladno – Luzna train, which connected with a Luzna – Krupa – Kolesovice special pulled by 434.1100, seen above running round the train at Kolesovice. Preserved railcar M131.1130 was also in operation.
Details from Rinbad.


[Derelict, rusting steam loco]

A very dead kettle in the railway museum at Luzna.


[Steam loco

Preserved loco in the Luzna museum. Only the front of it has been restored – inside the shed, some of the wheels are missing!


[Czech train]

A train for Tabor leaves Bechyne, over the impressive concrete viaduct which is shared with road traffic.


[View out of train window]

A Bechyne-bound train passing our train for Tabor. There are some more photos of this rather nice line on a 100th anniversary website.


[Diesel loco]

Diesel loco leaving at Jindrichuv Hradec on the 760 mm gauge JHMD line to Obratan.

Links

All changed from Limerick Junction

Monday, November 1st, 2010

Train at Galway station

“O Paddy dear, and did ye hear
The news that’s going round?”

The tunes whistled by old men on the next row of seats haven’t changed since I first encountered Iarnród Éireann a dozen or so years ago, but everything else at Ireland’s national railway has. Dirty diesel locomotives hauling old coaches with even more ancient passengers have gone, and in their place is this Dublin to Cork inter- city train of South Korean-built coaches packed with passengers drinking lattes as they tap away at laptops.

The reason for my return visit was the reopening at the end of March 2010 of the 58 km line from Ennis to Athenry. Known as the Western Rail Corridor, this creates a link between Limerick and Galway, and as such is almost unique as a route which doesn’t radiate from Dublin (Limerick Junction – Waterford has three trains a day). The line had retained some freight after the end of passenger services in 1976, but closed when this disappeared.

There aren’t many countries reopening rural lines, but the Irish government is trying to spread development, tackling fears that the entire working population might decided to move to Dublin. The €106·5m revival will increase options for commuting into Limerick and Galway, where traffic is now a growing problem, and further stations are planned to serve housing which is springing up.

A ticket for the two-hour journey costs €20. “A return is cheaper than a single”, advises the lady in the ticket office. Leaving Limerick every seat was taken, though few passengers went all the way through. There was quite a cross-section on board, from shrieking teenagers to pensioners, and a smartly dressed young couple, her carrying bags from fashion shops, him reading, of all things, Railway Modeller.

While it is literally true to describe the lines as an inter-city route, this wouldn’t reflect the reality of five trains a day, operated by two-car DMUs. Horses, sheep and goats observe the train from small fields divided by low stone walls, an enormous bull eyes us over his fence, and herons, rabbits or deer are never out of sight.

In the 1980s Ireland’s railways had been allowed to decay, and things came to a head with an accident in 1997. The perhaps surprising decision was taken to modernise rather than simply give up, just as the “Celtic tiger” economic boom and European Union money arrived. The results have been dramatic. It is easy to get sentimental about the old days of loco haulage and semaphore signals, but IÉ has modernised quickly and seems to be doing a more useful, if less picturesque, job than it once was.

The newly reopened stations look strongly built in concrete and steel, almost too industrial for a landscape of ruins and standing stones. New concrete bridges have replaced level crossings where possible, else modern barriers have been installed.

The line opens up new views. “I’ve never seen Gort from this side before” someone comments as we pause for a southbound train to pass. Looking at the state of a back garden I think the owner must have believed no-one ever would.

The connection to the Dublin – Galway main line at Athenry faces towards Dublin, and so the driver changes ends to take us into the terminus. Planning has begun to reopen the next 25 km to Tuam next year and 27 km to Claremorris some time after that, while the 74 km trackbed to Collooney is to be protected for a possible Sligo service.

Tied to a lamppost at Athenry is a sign from a local group which lobbied for the reopening of the railway. It simply says “welcome back”.

A ride on Kuala Lumpur’s railways

Wednesday, June 24th, 2009

A few pictures showing railways in and around Kuala Lumpur which I took in March 2002. Please note that the text is now somewhat out of date.

Kuala Lumpur seems to be trying to collect as many forms of rail transport as possible, with a conventional metro, an automatic metro, two different railway gauges and a monorail!

Putra

[Putra train]
One of the 70 linear induction motor powered vehicles on the Putra (Projek Usahasama Transit Ringan Automatik) metro.

[Kuala Lumpur skyline]
A view over Kuala Lumpur city centre from the front of a train. The trains are driverless, so passengers get a clear view out of the front window.

[View from train window]
The 29 km Putra metro is fully automatic.

KTMB

The KTM Komuter network is centred on Kuala Lumpur. Electrification began in 1995, and 160 km is now wired at 25 kV 50Hz AC. EMUs run from Seremban, south of KL on the main line to Singapore, to Rawang in the north, taking two hours. The second Komuter route provides Sentul to Port Klang services, which take about 1·5 hours.

Both routes pass through KL Sentral and Kuala Lumpur stations in the capital city, and run regularly from about 05.30 to midnight.

[Station]
The old station building in central Kuala Lumpur dates from 1886.

[Station]
To the north of and contiguous with the old station are more modern facilities, where all the train seemed to be stopping. The old station has a train shed and open access to the platforms, the new has substantial canopies and automatic ticket barriers controlling access. Platform heights vary between the parts. There is another new station, KL Sentral, to the south.

[KTMB locomotive]
Locomotive at KL

[KTMB shunters]
Shunters at KL

[KTMB locomotive]
Locomotive in KL station

[KTMB locomotive]
A locomotive at Rawang, the northern terminus of electrifed services in March 2002. Work is underway to double track and electrify the line northwards to Ipoh.

[Shunting locomotive]
This 0-6-0 diesel shunter was lurking at a cement works near Padang Jawa on the Port Klang line.

[EMUs]
KTMB metre-gauge EMUs stabled at Rawang, north of Kuala Lumpur.

[EMU interior]
Inside an EMU.

[EMU]
Another EMU, in the suburbs of Kuala Lumpur.

Star

[Star metro]
The Star metro in Kuala Lumpur is 27 km long, and serves 25 stations. Line 1 opened in 1996, Line 2 in 1998.

[Star metro train]
A Star driving car. Unlike Putra, Star is not automated.

Express Rail Link

[Express Rail Link]
View from the cab of a test train on the Express Rail Link. A KTMB train is on the metre-gauge line to the right.

[Express Rail Link Desiro train]
Our airport-bound test train passes another Siemens Desiro heading towards KL Sentral.
